RAM® Locking USB-C Powered Dock + USB-C Data for Tab Active5 Pro & 4 Pro (RAM-HOL-SAM57CPKL-CU)

RAM® Locking USB-C Powered Dock + USB-C Data for Tab Active5 Pro & 4 Pro (RAM-HOL-SAM57CPKL-CU)

RAM-HOL-SAM57CPKL-CU
Ex. Tax: $362.00 NZD
$362.00 NZD
Sale Sold out

The RAM® Locking USB-C Powered Dock + USB-C Data for Tab Active5 Pro (RAM-HOL-SAM57CPKL-CU) is designed to meet the demands of field workers in a variety of applications including transportation, field sales, logistics, manufacturing, and much more. Power and data sync capabilities are provided to the device through pogo pins, and you can easily rotate the device for use in portrait or landscape mode. For security and theft deterrence, this powered cradle features a key-lock that’s compatible with the RAM® Skin™ or factory device skin, as well as GDS® Hand-Stand™ and shoulder strap accessories. Access to the stylus remains while the device is docked. Included is a set of four nuts and bolts to connect the cradle to any RAM® components containing the universal AMPS hole pattern. Also included is the USB Type-C female pigtail, cable clamp, and zip ties.

Features

  • Key locking powered dock designed for Samsung Galaxy Tab Active5 Pro, Tab Active4 Pro, and Tab Active Pro with factory Samsung case or RAM® Skin™, powered via integrated pogo pin connector (Non-Power Delivery charger required)
  • Supports connection of one additional peripheral device via USB Type-C cable
  • RAM® Mounts Compatible™ with 4-hole AMPS pattern components
  • Constructed from high-strength composite materials for durability and reliability in demanding environments
  • Backed by a 3-year manufacturer warranty

Tech Specs

  • Product Weight: 1.25 lb
  • Hardware Included: (2) Keys | (4) #8-32 x 5/8" Machine Screws | (4) #8-32 Nylock Nuts | (1) Cable Clamp | (4) Large Cable Ties | (10) Small Cable Ties
  • Hole Pattern: 4-Hole AMPS: 1.181" x 1.496"
  • Materials: High strength composite
  • Packaging Type: Poly Bag
  • Input Voltage: 5.3-5.4VDC
  • Output Voltage: 5VDC
  • Power Output: 500mA
  • Input Connector: USB Type-C Female
  • Input Cable Length: 215mm
  • Output Connector: USB Type-C Female
  • Output Cable Length: 215mm
  • Peripheral Output: 500mAh
  • Transfer Speed: 480Mbps

Compatibility

  • Samsung: Tab Active Pro, Tab Active4 Pro, Tab Active5 Pro
Additional Information: This dock is not compatible with any Power Delivery (PD) Chargers. While the dock contains a USB-C connector, the pogo pads on the side of the tablet will not support Power Delivery. Therefore, a non-Power Delivery charger is required to function properly.

This product will not support the "No Battery Mode" function.

Package Content

  • 1 x RAM® Locking USB-C Powered Dock + USB-C Data for Tab Active5 Pro & 4 Pro (RAM-HOL-SAM57CPKL-CU)
